1、Product Introduction

The ZT260TA photoelectric turret consists of an uncooled infrared thermal imager, a 30x continuous zoom visible light camera, a laser rangefinder, a two axis servo stabilized platform, and an image tracker. It has the characteristics of light weight, high stability accuracy, and high integration, and can be applied to unmanned vehicles, armored vehicles, and sentries to complete tasks such as day and night reconnaissance, monitoring, and target positioning of target areas.

The photoelectric turret uses uncooled infrared thermal imagers and visible light cameras to detect, recognize, and track ground targets throughout the day, and outputs real-time infrared and visible light videos for task execution personnel to view.

Photoelectric turrets are mainly used in scenarios such as air detection, ground detection, border and coastal defense, monitoring of commanding heights, and border sentries.

2、Physical image

3、Product Features

a) Equipped with self inspection and fault reporting functions;

b) Capable of detecting long wave infrared and visible light bands, capable of outputting infrared and visible light images;

c) Visible light has optical zoom, automatic focusing, manual focusing, and low illumination functions;

d) Infrared has 1-4 times electronic amplification and six color palette switching functions;

e) Equipped with laser ranging function;

f) Having the ability to move with two degrees of freedom, including azimuth and pitch;

g) Equipped with various working modes such as automatic search/manual search/follow-up/automatic tracking/bookmarking;

h) In manual search mode, it has the function of receiving control station commands and completing tower turning operations;

i) Having the ability to isolate carrier disturbances and stabilize the line of sight;

j) Equipped with lock/unlock target function, and the output image of the turret after locking the target is an image with a tracking box;

k) Equipped with automatic target tracking function, capable of automatically tracking targets, and capable of resisting natural interference;

l) Equipped with memory tracking function, the target can be recaptured in a short period of time after being briefly lost;

m) Having the function of adjusting the size of the wave gate;

n) Equipped with tracking point switching function;

o) Target coordinates can be calculated based on laser ranging and vehicle attitude information;

p) It can communicate with the control station in both directions through RS422/100Mbps network, and output information such as infrared images, visible light images, system operation status, camera operation status, optical axis position, etc;

q) Equipped with network/HD-SDI video output interface;

r) Capable of taking photos and recording videos;

s) Equipped with target positioning function;

t) The optical cabin is airtight.

4、Carrying platform

Unmanned vehicles, armored vehicles, monitoring towers, etc.

5、Main technical parameters

6、 Mechanical dimensions and installation interfaces

Figure 2 Product Mechanical Dimensional Drawing and Product Installation Interface Drawing
